Separate Component Computer
Connection Method
- Camera Integration: Supports up to 4 camera modules via professional BNC native interfaces[cite: 26].
- Video Input: Connect external signal sources through 1x HDMI IN[cite: 27].
- Display Output: Supports dual HDMI OUT for multi-screen mirroring or extension[cite: 28].
- Data Connectivity: Features USB 3.0, USB 2.0 [cite: 29], and 1x full-function Type-C port[cite: 30].
- Audio & Network: Includes WiFi 6 [cite: 34], Bluetooth 5.0 [cite: 35], MIC IN [cite: 31], and AUDIO OUT interfaces[cite: 32].
Aula One Performance Core Core
CPU Architecture
8-Core Architecture Processor
AI Computing Power
6 TOPS NPU Dedicated AI Unit
System Memory (RAM)
16GB LPDDR4x
Storage Capacity
128G / 256G / 512G Options (Supports SSD Expansion )
Ultra-HD Video Decoding
Up to 8K@60fps (H.265/VP9/AVS2) & 4K@60fps (AV1) [cite: 13]
Ultra-HD Video Encoding
Up to 8K@30fps (H.265 / H.264)
Interactive Display
11" Multi-Touch Full-Lamination Screen
Structural Hinge
Zero-Gravity Hinge Technology for Smooth Rotation
| Features | 58mm Medium-Telephoto Module | 26mm Ultra-Wide Angle Module |
|---|---|---|
| Optical Resolution | 8MP / 4K (3840*2160 @ 25fps) | 8MP / 4K (3840*2160 @ 25fps) |
| Sensor Type | 8MP High-Sensitivity Sensor | 8MP High-Sensitivity Sensor |
| Aperture | F1.8 (High light intake) | F2.0 (Balanced light intake) |
| Focusing Technology | LDAF Laser Autofocus | LDAF Laser Autofocus |
| Field of View (H/V) | 36.3° (H) / 20.9° (V) | 72° (H) / 44.8° (V) |
| Min. Focus Distance | 30cm | 5cm (Macro Extreme Focus) |
| Weatherproof Rating | IP65 Waterproof | IP65 Waterproof |
| Physical Specs | 38*42*42mm / 120g | 38*42*42mm / 120g |
| Mounting | Triple-direction 1/4" screw | Triple-direction 1/4" screw |
System Interfaces & Connectivity
Camera Inputs
4x BNC Native Interfaces (For Split Modules)
Video Input
1x HDMI IN
Video Output
2x HDMI OUT
USB Expansion
1x USB 3.0 / 2x USB 2.0
Full-Function Port
1x Type-C Interface
Audio I/O
1x MIC IN / 1x AUDIO OUT
Wireless Network
WiFi 6 (802.11ax) & Bluetooth 5.0
Network Port
Integrated Ethernet Port
Physical & Power Specifications
Operating System
AulaOS + Android 12
Display & Interaction
11" Multi-Touch Industrial Screen with Zero-Gravity Hinge
Material & Color
Space Gray Eco-friendly Aluminum
Power Supply
12V Power Input
Power Consumption
< 25W (Full Load)
Operating Temp
0℃ to 50℃
Dimensions
259.8 * 162.5 * 73 mm
Weight
2126 g
